GIGABYTE S453-S70-AAV1 Server

Chassis:

• 4U 36 Bay SFF or LFF
• 24x 2.5" SATA/SAS front + 12x 2.5" SATA/SAS back
• 24x 3.5" SATA/SAS front + 12x 3.5" SATA/SAS back

Processor types:

• 2 x Intel Xeon 4th Gen Scalable
• 2 x Intel Xeon 5th Gen Scalable
• Up to 64 Cores / 128 Threads Processor
• Socket: Intel Socket 4677
• Up to 270W per processor

Memory RAM types:

• 16 Slots, 2 channels
• 8 channel memory per processor
• Max configuration: 1TB DDR5 4800 MT/s - 4th Gen Scalable CPU
  16 x 64GB ECC Registered
• Max configuration: 1.5TB DDR5 5600 MT/s - 5th Gen Scalable CPU
  16 x 96GB ECC Registered

Storage Options 2.5" Drives
2 x M.2 Gen4

• NVMe M.2: up to 4TB
• SAS SSDs: 15.36TB @ 12GB/s
• SATA SSD: 15.36TB @ 6GB/s

Expansion Slots:

• 6 x PCIe Gen5 x16 Low-profile

LAN Functions

• 2 x 10Gb/s LAN (1 x Intel X710-AT2)
• 2 x 1Gb/s LAN (2 x Intel I210-AT)

Operating Systems:

• Windows Server 2022
• Windows Server 2019
• Ubuntu 22.04 LTS
• SuSE Linux Enterprise
• RHEL 9.x
• CentOS
• VMware

Power Supplies:

• 1+1 Redundant 2000W 80 PLUS Platinum
• 1+1 Redundant 2000W 80 PLUS Titanium
• 1+1 Redundant 1600W 80 PLUS Platinum
• 1+1 Redundant 1600W 80 PLUS Titanium

Storage Controllers RAID Options:

• Broadcom MegaRAID 9560-16i
• Broadcom MegaRAID 9560-8i
• Broadcom HBA 9500-8i Tri-Mode
• Broadcom HBA 9500-16i Tri-Mode
• Graid SupremeRaid SR1000 GPU cards
• Graid SupremeRaid SR1010 GPU cards
• Graid SupremeRaid SR1001 GPU cards

Network Interface Card Options (NICs) PCIe

• INTEL i350-AM4
• INTEL i350-AM2
• INTEL X550-AT2
• INTEL X550-AT2
• INTEL XL710-BM2
• INTEL XL710-BM1
