ASUS RS520A-E12-RS24U 2U 24 Bay SFF

SKU: RS520A-24B-SFF-16NVMe+8SAS-SATA

Chassis
Qty
Price
16 Bay SFF NVMe + 8 Bay SFF SAS/SATA
1
$2,549.00
Price as configured
Regular price
$2,549.00
Sale price
$2,549.00
Unit price
per

Tech Specs

Chassis:

  • Front Flex Bay 2U - 24 x 2.5" SATA/SAS/NVMe SSDs with 3 possible variants
  • 16 x NVMe + 8 x SAS/SATA
  • 12 x NVMe + 12 x SAS/SATA
  • 24 x NVMe

Processor types:

  • 1 x AMD EPYC 9004 Genoa CPUs
    Generation
  • Up to 128 Cores Processor
  • Up to 400W TDP for processor
  • Socket: SP5 LGA-6096

Memory RAM types:

  • 24 Slots, 12 channels
  • 12 channels 2 slots per channel
  • Max configuration: 6TB DDR5 4800 MT/s
    24 x 256GB ECC Registered

Storage Options 2.5" Drives
2 x M.2 Gen4

  • NVMe M.2: 3.84TB
  • SAS SSDs: 7.68TB @ 12GB/s
  • SATA SSD: 15.36TB @ 6GB/s
  • NVMe U.2: 7.68TB

GPU Options:

  • Up to 4 Single-Slot GPU Cards
  • Up to 2 double-slot GPU cards
  • 24 x NVMe variant does not support GPU cards.

Operating Systems:

  • Windows Server 2019
  • Windows Server 2022
  • Ubuntu 22.04 LTS
  • ESXi 8.0
  • RHEL 8.x
  • RHEL 9.x

Power Supplies:

  • 1+1 Redundant 1600W 80 PLUS Titanium
  • 1+1 Redundant 1600W 80 PLUS Platinum
  • 1+1 Redundant 1200W 80 PLUS Platinum

Storage Controllers RAID Options:

  • Broadcom Mega RAID 9560-16i
  • ASUS PIKE II 3008-8i 8-port SAS 12G HBA card

Security:

  • Trusted Platform Module
  • PFR Module

Network Interface Card Options (NICs)

  • Integrated: Intel i350-AM2
    2x 1GbE RJ45 onboard LAN
  • 1 x Management LAN Port

Expansion Slots:

  • 2x PCIe x16 Gen5 Full Height
  • 4x PCIe x8 Gen5 Full Height
  • 1x PCIe x8 Gen5 Low Profile
  • 1 x OCP3.0 Socket Gen5

ASUS RS520A-E12-RS24U Supported CPUs

CPU Cores/Threads Frequency Turbo Frequency
AMD EPYC 9124 16C/32T 3.00GHz 3.70GHz
AMD EPYC 9174F 16C/32T 4.10GHz 4.40GHz
AMD EPYC 9184X 16C/32T 3.55GHz 4.10GHz
AMD EPYC 9224 24C/48T 2.50GHz 3.70GHz
AMD EPYC 9254 24C/48T 2.96GHz 4.15GHz
AMD EPYC 9274F 24C/48T 4.05.10GHz 4.30GHz
AMD EPYC 9334 32C/64T 2.70GHz 3.90GHz
AMD EPYC 9354 32C/64T 3.25GHz 3.80GHz
AMD EPYC 9354P 32C/64T 3.25GHz 3.80GHz
AMD EPYC 9374F 32C/64T 3.85GHz 4.30GHz
AMD EPYC 9384X 32C/64T 3.10GHz 3.90GHz
AMD EPYC 9454 48C/96T 2.75GHz 3.80GHz
CPU Cores/Threads Frequency Turbo Frequency
AMD EPYC 9454P 48C/96T 2.75GHz 3.90GHz
AMD EPYC 9474F 48C/96T 3.60GHz 4.10GHz
AMD EPYC 9534 64C/128T 2.45GHz 3.70GHz
AMD EPYC 9554 64C/128T 3.10GHz 3.75GHz
AMD EPYC 9554P 64C/128T 3.10GHz 3.75GHz
AMD EPYC 9634 84C/168T 2.25GHz 3.70GHz
AMD EPYC 9654 96C/192T 2.40GHz 3.70GHz
AMD EPYC 9654P 96C/192T 2.40GHz 3.70GHz
AMD EPYC 9684X 96C/192T 2.55GHz 3.70GHz
AMD EPYC 9734 112C/224T 2.20GHz 3.00GHz
AMD EPYC 9754 128C/256T 2.25GHz 3.10GHz

ASUS RS520A-E12-RS24U RAID Options

RAID Options RAID Levels Cache Drive Speeds PCIe Generation RAID Hardware
Broadcom Mega RAID 9560-16i 0, 00, 1, 5, 6, 10, 50 and 60 N/A 12Gb/s SAS | 16GT/s NVMe 4.0 Yes
