SSD Tray Compatibility:
2.5" Tray: R340 8 Bay SFF, R440 8 Bay SFF, R440 10 Bay SFF, T440 16 Bay SFF, T640 32 Bay SFF, T640 16 Bay SFF, R640 10 Bay SFF, R740 16 Bay SFF, R740xd 24 Bay SFF, R940 24 Bay SFF, M640, FC640, R6515 8 Bay SFF, R6525 8 Bay SFF, R7515 24 Bay SFF, R7525 24 Bay SFF, R7525 16 Bay SFF, R7525 8 Bay SFF, R350 8 Bay SFF, R450 8 Bay SFF, R550 8 Bay SFF, R550 16 Bay SFF, C6525 24 Bay SFF
3.5" Tray with 2.5" to 3.5" Adapter: R240 4 Bay LFF, R340 LFF, R440 4 Bay LFF, T440 4 Bay LFF, T440 8 Bay LFF, R540 12 Bay LFF, R540 2 Bay LFF, R640 4 Bay SFF, R740xd 12 Bay LFF, R6515 4 Bay LFF, R6525 4 Bay LFF, R7515 8 Bay LFF, R7515 12 Bay LFF, R7525 12 Bay LFF, R7525 8 Bay LFF, R250 2 Bay LFF, R250 4 Bay LFF, R350 4 LFF, R450 4 Bay LFF, R550 8 Bay LFF, C6525 12 Bay LFF
SSD Specifications
| Warranty |
1 Year or Total Bytes Written |
|||||
| Disclaimer: Cloud Ninjas is not responsible for transferring of data | ||||||
| Spec |
Interface |
SATA III | ||||
|
Dimension |
69.85 x 100.00 x 9.50 mm | |||||
|
Weight |
62~72 g | |||||
|
Capacity |
256GB | |||||
|
SDram |
N/A | |||||
|
Flash Type |
TLC NAND | |||||
| Read/Write Performance |
Sequential Read |
520MB/s | ||||
|
Sequential Write |
300MB/s | |||||
|
4KB Random Read IOPS |
97K | |||||
|
4KB Random Write IOPS |
10K | |||||
| Power Consumption |
Power Supply |
+5V ± 5% | ||||
|
Maximum Ripple |
100 mV(peak to peak) | |||||
|
4KB Random Write |
2.7W | |||||
| Reliability |
"Endurance: 438 TBW at 1 drive write per day over 5 years" |
|||||
|
MTBF: 2,000,000 hours |
||||||
|
"Data retention: 3 months @ 40℃ in power-off state" |
||||||
|
Data destroy not supported |
||||||
|
Sudden power-off recovery support |
||||||
|
S.M.A.R.T., NCQ, Trim and dynamic power management support |
||||||
|
Static and dynamic wear-leveling |
||||||
|
Bad block management algorithm |
||||||
| Environment |
Operating temperature: 0℃~70℃ |
|||||
|
Non-Operating temperature: -40℃~85℃ |
||||||
|
Humidity: 5%~95% |
||||||
|
Vibration |
20G (20Hz to 2000Hz) | |||||
|
Shock |
1500G at 0.5ms | |||||
