Workstation for XSplit Broadcaster
XSplit Broadcaster is a professional live production application used to stream and record games, presentations, events, and other media. It combines multiple video and audio sources into customizable scenes and supports live broadcasting, local recording, capture cards, webcams, screen capture, browser sources, virtual cameras, and professional production tools.
The Cloud Ninjas XSplit Broadcaster workstation is designed for streamers, content creators, broadcasters, esports professionals, and production teams running demanding live-streaming and recording workflows. A capable CPU and GPU provide the processing resources required to manage multiple sources, scenes, effects, captures, and hardware-accelerated encoding while maintaining a responsive production environment.
- AMD Ryzen Processor
- DDR5
- NVIDIA GPU
- Ryzen Edition Workstation for Broadcaster
Configure your Cloud Ninjas Workstations for XSplit Broadcaster Ryzen Edition
Workstation for XSplit Broadcaster
Hardware Encoding for XSplit Broadcaster
Hardware video encoding allows XSplit Broadcaster to use dedicated encoding engines on supported GPUs and processors rather than performing the entire encoding workload on general-purpose CPU cores. XSplit specifically supports NVIDIA NVENC for hardware-accelerated streaming and recording, including AV1 encoding on supported NVIDIA GPUs.
XSplit has also expanded H.265/HEVC hardware encoding support to Intel Quick Sync Video and AMD VCE, in addition to NVIDIA NVENC. This gives compatible systems multiple hardware encoding options depending on the installed processor and GPU.
Hardware encoding is particularly valuable for live streaming because it can reduce CPU utilization and leave more processing capacity available for games, applications, scene composition, and other production tasks.
CPU Performance for XSplit Broadcaster
The CPU supports the general-purpose portions of an XSplit production environment, including application processing, source management, scene logic, audio processing, browser sources, plugins, and other tasks that are not handled by dedicated hardware encoders.
CPU resources become increasingly important as a production becomes more complex. Running XSplit alongside a game, video-editing application, browser windows, chat applications, recording software, or other production tools can create additional CPU demand even when hardware video encoding is enabled.
A high-performance processor provides additional headroom for these concurrent workloads and helps maintain responsiveness when the workstation is being used as a complete production system rather than solely as a streaming encoder.
GPU Performance for XSplit Broadcaster
The GPU performs more than video encoding in an XSplit production environment. Broadcaster can use GPU resources for rendering scenes, processing visual sources, capturing applications and games, applying effects, and other graphics-intensive operations. XSplit also provides a GPU Priority setting intended to give Broadcaster's GPU processes higher priority when sharing the GPU with other applications.
GPU requirements therefore increase as a production uses higher-resolution sources, more visual effects, multiple displays, game capture, animated overlays, and other graphics-intensive elements. When streaming a GPU-intensive game from the same system, sufficient GPU headroom is particularly important because the game and Broadcaster are competing for graphics resources.
Cloud Ninjas Workstations for XSplit Broadcaster Ryzen Edition Specifications
The CPU plays a critical role in software-based encoding, scene rendering, and plugin execution. XSplit Broadcaster benefits from strong multi-core and multi-threaded CPU performance for handling encoding workloads, while solid single-core performance improves responsiveness when switching scenes or adjusting live elements during broadcasts.
| CPU | Cores & Threads | Base Clock | Turbo Clock |
|---|---|---|---|
| AMD Ryzen 7 9700X | 8C/16T | 3.80 GHz | 5.50 GHz |
| AMD Ryzen 7 9800X3D | 8C/16T | 4.70 GHz | 5.20 GHz |
| AMD Ryzen 9 9900X | 12C/24T | 4.40 GHz | 5.60 GHz |
| AMD Ryzen 9 9900X3D | 12C/24T | 4.40 GHz | 5.50 GHz |
| AMD Ryzen 9 9950X | 16C/32T | 4.30 GHz | 5.70 GHz |
| AMD Ryzen 9 9950X3D | 16C/32T | 4.30 GHz | 5.70 GHz |
GPU acceleration enhances XSplit Broadcaster performance through hardware encoding and real-time visual processing. A workstation GPU with efficient encoding capabilities and sufficient VRAM reduces CPU load, enables smoother high-resolution streaming, and supports advanced visual effects. GPU acceleration is essential for maintaining performance when running demanding streaming workflows alongside other professional applications.
| GPU | VRAM | GPU Clock | Memory Clock |
|---|---|---|---|
| NVIDIA RTX PRO 6000 Blackwell Workstation Edition | 96GB GDDR7 | 1750 MHz | 2617 MHz |
| NVIDIA RTX PRO 6000 Blackwell Max Q Workstation Edition | 96GB GDDR7 | 2280 MHz | 1750 MHz |
| NVIDIA RTX PRO 5000 Blackwell | 48GB GDDR7 | 2377 MHz | 1750 MHz |
| NVIDIA RTX PRO 4500 Blackwell | 32GB GDDR7 | 2407 MHz | 1750 MHz |
| NVIDIA 6000 ADA Generation | 32GB GDDR6 | 2505 MHz | 2500 MHz |
| NVIDIA RTX 5090 | 32GB GDDR7 | 1750 MHz | 2407 MHz |
| NVIDIA RTX 5000 ADA Generation | 32GB GDDR6 | 2550 MHz | 2250 MHz |
| NVIDIA RTX 4500 ADA Generation | 24GB GDDR6 | 2580 MHz | 2250 MHz |
| NVIDIA RTX 4000 ADA Generation | 20GB GDDR6 | 2175 MHz | 2250 MHz |
| NVIDIA RTX 5080 | 16GB GDDR7 | 1875 MHz | 2617 MHz |
| NVIDIA RTX 5070 Ti | 16GB GDDR7 | 1750 MHz | 2452 MHz |
| NVIDIA RTX 5070 | 12GB GDDR7 | 1750 MHz | 2512 MHz |
| NVIDIA RTX 5060 Ti | 16GB GDDR7 | 1750 MHz | 2572 MHz |
| NVIDIA RTX A1000 | 8GB GDDR6 | 1462 MHz | 1500 MHz |
| NVIDIA RTX A400 | 4GB GDDR6 | 1762 MHz | 1500 MHz |
Gaming and Live Streaming on One PC
XSplit Broadcaster can capture games running through DirectX 9–12, Vulkan, and OpenGL, making it suitable for PC gaming streams and recorded gaming content.
Running the game and streaming application on the same workstation creates a shared-resource environment. The game requires GPU and CPU resources for rendering and simulation while Broadcaster simultaneously captures the game, composites the scene, processes additional sources, and encodes the outgoing stream.
A high-performance streaming workstation provides additional CPU and GPU headroom for maintaining game performance while producing a high-quality live broadcast.
Multi-Camera and Capture Card Streaming
XSplit Broadcaster supports camera and capture-card sources, allowing multiple physical video devices to be incorporated into a single production. Cameras can be arranged into scenes, combined with screen captures, presentations, browser content, and other sources, and switched during a live production.
Multi-camera productions place greater demands on the workstation because multiple video feeds must be captured, processed, composited, and encoded in real time. Capture-card selection, source resolution, frame rate, color format, and the number of active sources all affect the processing requirements.
