Dell PowerEdge T560 Network Card Options
Increase and update your business infrastructure by upgrading the network cards of your Dell PowerEdge T560 server, and experience the difference in transfer speeds and performance over your network with Cloud Ninjas's selection.
- RJ45, SFP28
- 1GbE, up to 100GbE
- PCIe Express & OCP 3.0 Cards
- Max Quad-port
CONTACT FOR INQUIRES:
sales@cloudninjas.com
Filters
Dell PowerEdge T560 Network Cards
9 Items
Dell PowerEdge T560 Compatible Network Cards
The Dell PowerEdge T560 is a tower server with possibilities for up to two Network Interface cards on the back panel. The NIC speeds for the Dell PowerEdge T560 are, 1GbE, 2.5GbE ,10GbE, 25GbE, 40GbE, and 100GbE. Only PCIe express and OCP 3.0 cards are accepted on the T560. RJ45 and SFP28 are the interface connector types the Dell PowerEdge T560 can support. Fibre channel cards are not compatible with the T560. NIC cards can come with an optional low-profile metal bracket or high-profile metal bracket, make sure you choose your option correctly. Some Network cards might have two variations, a low-profile variation and a full-height variation, which is based on the physical size of the card.
Technical Guide
Cloud Ninjas Dell PowerEdge T560 Network Card Upgrade Tips
-
There are 2 different types of interfaces: RJ45 and SFP28.
-
There are multiple port speeds: 1GbE, 2.5GbE, 10GbE, 25GbE, 40GbE, and 100GbE.
-
Maximum port speed for the T560 is 100GbE (Gigabits over Ethernet).
-
The T560 does not support fibre channel cards over PCIe express.
-
The Dell PowerEdge T560 accepts up to 2 NICs on the back panel of the chassis.
